core100
Designed for curing lightweight coatings and inks on narrow webs
Designed for curing lightweight coatings and inks on narrow webs
The Core 100 can accommodate virtually any flexible packaging handled by the HP Indigo 20000 press, or any other digital printing press, including inkjet.
With a top speed of up to 600 fpm, it can keep up with multiple presses in a production facility. This facilitates both inline and offline configurations.
With numerous options for overprint varnish (OPV) finishes, you can choose the best effect to make your packaging stand out on any shelf.
Best of all, ebeam’s instant-curing process means you can turn around orders in an instant!
Technical Specifications | Values |
Accelerating Voltage | 80 to 100 kV |
Maximum Uniform Beam Width | 760 mm |
Maximum Production Speed | 183 m/min |
Maximum Surface Dose Rate for 100 kV | 30 kGy @ 183 m/min |
Cross-web Uniformity | ≤ ±8.0% variation |
Nitrogen Inerting Level | ≤ 200 ppm O2 |
Web Support | Patented integrated shield roll |
Dimensions (H x W x D) | 100 x 255 x 149 cm |
Facility Requirements | Electricity, cooling water, and nitrogen |
Noise Level | < 70.0 dB(A) |
